TP-Link Media Converter MC220L - GigE

TP-Link Media Converter MC220L - GigE_1
Article-No.:
501496
Manufacturer-No.:
MC220L
EAN/GTIN:
6935364030476
WEEE Nummer
DE85565951
Compare
Print view

Suitable products

Similar products

Technical specifications

Description

Technical specifications

General

Packaged Quantity
1

Networking

Type
Fiber media converter
Form Factor
External
Data Transfer Rate
1 Gbps
Max Transfer Distance
10 km
Optical Wave Length
850 nm / 1310 nm

Connectors (for SD)

Right Connector Type
SFP (mini-GBIC)
Left Connector Type
RJ-45

Expansion Slots

Expansion Slots
1 (total) / 1 (free) x SFP (mini-GBIC)

Cable

Left Connector Type
RJ-45
Right Connector Type
SFP (mini-GBIC)

Power Device

Type
External power adapter

Dimensions & Weight

Width
9,5 cm
Depth
7,3 cm
Height
2,7 cm

Compatibility

Description
P/N: TL-MC1400
Specs
P/N: TL-MC1400
Description
The MC220L is a media converter designed to convert 1000Base-SX/LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards, the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the SC/LC-Type connector. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.
Other features of this module include the ability to be used as a standalone device (no chassis required) or with TP-Link's 19"system chassis, Auto MDI/MDI-X for TX port, and front panel status LEDs. The MC220L will transmit at extended fiber optic distances utilizing multi-mode fiber up to 0.55 kilometers and 10 kilometers when utilizing single-mode fiber.
