TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable

TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable_thumb_1
TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable_thumb_2
TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable_thumb_3
TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable_1
TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable_2
TP-Link JetStream TL-SG3428 - switch - 28 ports - managed - rack-mountable_3
Article-No.:
149985
Manufacturer-No.:
SG3428
EAN/GTIN:
6935364010713
WEEE Nummer
DE85565951
Compare
Print view

Suitable products

Technical specifications

Description

Technical specifications

General

Packaged Quantity
1

Performance

Performance
Switching capacity: 56 Gbps, Packet forwarding rate: 41.66 Mpps

Ports

Qty
24
Type
10/100/1000

Second Ports

Qty
4
Type
Gigabit SFP

Capacity

Capacity
ARP entries: 316, Maximum aggregation groups: 8, VLAN groups: 4000, Priority queues: 8, Ports per aggregation group: 8

Networking

Type
Switch
Ports Qty
28
Routing Protocol
MLDv2, MLD, IGMPv2, IGMP, IGMPv3
MAC Address Table Size
8K entries
Jumbo Frame Support
9KB

Power Device

Power Consumption Operational
19,22 Watt
Frequency Required
50/60
Nominal Voltage
AC 120/230 V
Type
Internal power supply

Dimensions & Weight

Width
44 cm
Depth
18 cm
Height
4,4 cm

Miscellaneous

Color Category
Black
Description
TP-Link's JetStream L2/L2+ managed switches provide high performance, powerful L2 and L2+ features like static routing, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-Port Binding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-of-Service (Dos) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitates network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link JetStream L2/L2+ managed switches provide a reliable, secure solution for enterprise, campus and ISP networks.
  • Networking security
    The L2/L2+ managed switches provide IP-MAC-Port Binding, Port Security, Storm control and DHCP Snooping which protect against broadcast storms, ARP attacks, etc. It integrates some typical Dos attacks to select. You can protect these attacks more easily ever than before. In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports and even VLAN ID. Moreover, the switch supports 802.1X authentication, which is used in conjunction with a RADIUS/TACACS+ server to require some authentication information before access to the network is allowed.
  • Advanced QoS features
    To integrate voice, data and video service on one traffic based on a variety of means including IP or MAC address, TCP or UDP port number, etc. to ensure that voice and video are always clear, smooth and jitter free. In conjunction with the Voice VLAN the switch supporting, the voice applications will operate with much smoother performance.
  • Abundant L2 and L2+ features
    The L2/L2+ managed switches support a complete lineup of L2 features, including 802.1Q VLAN, Port Mirroring, STP/ RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow Control function. Any more, the switch provides advanced features for network maintenance. Such as Loopback Detection, Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling and filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Moreover, L2/L2+ managed switches support L2+ feature-static routing, which is a simple way to provide segmentation of the network with internal routing through the switch and helps network traffic for more efficient use.
  • ISP features
    The L2/L2+ managed switches support a bundle of ISP features such as 802.3ah OAM, DDM, sFlow, QinQ, L2PT PPPoE ID Insertion, IGMP authentication etc. 802.3ah OAM and Device Link Detection Protocol (DLDP) functions improve monitor and troubleshoot Ethernet networks, help facilitate network management. DDM (Digital Diagnostic Monitoring) function helps view the status of SFP modules inserting to the switch and to configure alarm settings, warning settings, temperature threshold settings, voltage threshold settings, bias current threshold settings, TX power threshold settings, and Rx power threshold settings.
  • IPv6 support
    The L2/L2+ managed switches support various IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discovery, which guarantees your network is ready for the Next Generation Network (NGN) without upgrading your network equipment.
