Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable

Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable_thumb_3

Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable_thumb_4

Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable_1

Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable_2

Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable_3

Ubiquiti UniFi Pro Max - switch - 24 ports - rack-mountable_4

Article-No.:

263556

Manufacturer-No.:

USW-PRO-HD-24-POE

WEEE Nummer

DE46285170

Compare

Print view

Suitable products

Ubiquiti UI Care - extended service agreement - 5 years - shipment

Technical specifications

General

Packaged Quantity

Chassis

Built-in Devices

1.3" touch screen display

Performance

Non-blocking switching throughput: 56 Gbps, Switching capacity: 112 Gbps, Forwarding rate: 83 Mpps

Ports

Qty

Type

10GBase-T (PoE++)

Second Ports

Qty

Type

2.5GBase-T (PoE++)

Third Ports

Qty

Type

10 Gigabit SFP+

Capacity

VLANs supported: 1000, IPv4 routes: 512, ARP entries: 6000

Networking

Type

Switch

Ports Qty

Routing Protocol

Static IP routing, RSTP, STP

MAC Address Table Size

16000 entries

Power Over Ethernet (PoE)

PoE++

Advanced Switching

Layer 3

PoE Budget

600 W

Power Device

Power Consumption Operational

50 Watt

Voltage Required

AC 100-240

Frequency Required

50/60

Power Provided

660 Watt

Nominal Voltage

AC 120/230 V

Features

DC power backup

Type

Internal power supply

Dimensions & Weight

Width

44,2 cm

Depth

32,5 cm

Height

4,4 cm

Weight

4,2 kg

Compatibility

Description

P/N: UACC-CABLE-PATCH-EL-0.15M-W, UACC-DAC-SFP10-0.5M

Specs

P/N: UACC-CABLE-PATCH-EL-0.15M-W, UACC-DAC-SFP10-0.5M

Miscellaneous

Height (Rack Units)

Color Category

Gray

Description

Experience seamless networking with the Ubiquiti UniFi Pro Max. This switch offers a robust capacity for 1000 IPv4 routes, 6000 ARP entries, and support for up to 512 VLANs, making it suitable for managing high-performance networks. The unit features a user-friendly 1.3-inch touch screen display for easy navigation and management, ensuring efficient control over network settings. Its 24 ports, consisting of 2.5GBase-T and 10GBase-T options, allow for flexible connectivity to meet various network demands.
Designed to operate reliably in diverse environments, the Ubiquiti UniFi Pro Max can function between temperatures of -5°C to 40°C and operates efficiently within a humidity range of 10-90%, non-condensing. This rack-mountable switch supports features like Layer 2 and Layer 3 switching, IGMP snooping, and static routing, making it a versatile solution for any organization seeking efficient network management and performance.

High capacity performance
The Ubiquiti UniFi Pro Max supports up to 1000 IPv4 routes and 6000 ARP entries, providing ample capacity for larger networking environments.
Versatile connectivity options
With 24 ports, including 2.5GBase-T and 10GBase-T, this switch offers flexible connectivity to cater to various network needs.
Reliable environmental operation
Operates in a wide temperature range from -5°C to 40°C and within a humidity range of 10-90%, suitable for different operational settings.
Robust networking features
Incorporates advanced networking capabilities such as IGMP snooping, Layer 2 and Layer 3 switching, and static routing to enhance network performance.
User-friendly design
Equipped with a 1.3-inch touch screen display, this switch facilitates easy management and navigation through its features and settings.
