Article-No.:

216884

Manufacturer-No.:

MAGFLOW-3

EAN/GTIN:

4711173877592

WEEE Nummer

DE30626183

Compare

Print view

Technical specifications

General

Product Type

Case fan

Packaged Quantity

Heatsink & Fan

Fan Diameter

120 mm

Fan Height

26.6 mm

Rotation Speed

600-2000 rpm

Air Flow

63.33 cfm

Features

Daisy-chain design, Magnetic connection system, PWM control

Fan Bearing

Fluid dynamic bearing

Air Pressure

2.61 mm

Noise Level

9.9 - 33.78 dBA

Dimensions & Weight

Width

36,58 cm

Depth

2,66 cm

Height

124 cm

Service & Support

Type

3-year warranty

Miscellaneous

Color Category

Black

Description

Thanks to the very innovative magnetic connection system, the installation of MagFlow fans will be fast and effortless.

Daisy chain design
Individual fans are attached to each other by an interlocking mechanism supported by magnets. This system eliminates the use of wires to make the installation simpler and cleaner.
Modularity
Regardless of the number of fans to be installed, attaching the cables for power and signal becomes extremely easy and convenient with the magnets. The connectors snap quickly and precisely in place, which greatly simplifies the assembly process.
Construction
The solid construction of the fan with Fluid Dynamic Bearing (FDB) is the result of a high precision manufacturing process.
