QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable

QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_thumb_1
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_thumb_2
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_thumb_3
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_thumb_4
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_thumb_5
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_thumb_6
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_1
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_2
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_3
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_4
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_5
QNAP QSW-M2108R-2C - switch - 10 ports - managed - rack-mountable_6
Article-No.:
156533
Manufacturer-No.:
QSW-M2108R-2C
EAN/GTIN:
4713213518762
WEEE Nummer
DE90799723
Compare
Print view

Similar products

Technical specifications

Description

Technical specifications

General

Packaged Quantity
1

Performance

Performance
Non-blocking switching throughput: 40 Gbps, Switching capacity: 80 Gbps

Ports

Qty
8
Type
2.5GBase-T

Second Ports

Qty
2
Type
Combo 10 Gigabit SFP+/RJ-45

Networking

Type
Switch
Ports Qty
10
MAC Address Table Size
16K entries
Jumbo Frame Support
9KB

Power Device

Power Consumption Operational
60 Watt
Frequency Required
50/60
Nominal Voltage
AC 120/230 V
Type
Internal power supply

Dimensions & Weight

Width
20,7 cm
Depth
19,95 cm
Height
4,33 cm
Weight
1,2 kg

Dimensions & Weight (Shipping)

Shipping Weight
1,92 kg

Service & Support

Type
2-year warranty

Miscellaneous

Height (Rack Units)
1
Color Category
Black
Description
The QSW-M2108R-2C is a Layer 2 Web Managed Switch with two 10GbE SFP+/RJ45 combo ports and eight 2.5 Gigabit ports. Supporting Layer 2 switching and network management via a user-friendly web user interface, the QSW-M2108R-2C offers flexible deployment in hybrid high-speed network environments and provides an entry-level network management solution. With a half-width design, two QSW-M2108R-2C can be installed in a 1U rack space for space-saving. The QSW-M2108R-2C is compatible with 10GbE and NBASE-T technologies, supporting up to five speeds (10G / 5G / 2.5G / 1G / 100M) to provide higher transmission speeds when using existing Cat 5e and 6a cables.
  • Half-width design, 2 models in 1U
    With a half-width rackmount design, two QSW-M2108R-2C can be installed in a 1U rack space for efficient physical space utilization and tidy cabling.
  • Flexible deployment with multiple 10G SFP+ fiber and Gigabit ports
    The QSW-M2108R-2C provides two 10GbE SFP+/RJ45 combo ports and eight 2.5 Gigabit ports for connecting various devices and enabling hybrid high-speed networks. With SFP+ interfaces, Direct Attach Copper (DAC) cables can be used for connecting directly to SFP+ devices. You can also use RJ45 ports to connect 10GBASE-T/NBASE-T devices through RJ45 Category 6 (or better) cabling. The switching capacity of the QSW-M2108-2C is 80Gbps, guaranteeing the full potential of each port.
  • Flexible deployment combo ports and 10GbE / NBASE-T
    The QSW-M2108R-2C is compatible with 10GbE and NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M) using existing Cat 5e and Cat 6a cables. The SFP+/RJ45 (copper) combo ports provide higher transmission speeds with existing cables. Depending on cable type and lengths, different speeds can be achieved for faster, more efficient data transfer.
Product content

Product content

  • QNAP QSW-M2108R-2C
  • Power cord
  • Rack mounting kit
