Article-No.:
144415
Manufacturer-No.:
QGD-1600P-4G
EAN/GTIN:
4713213516195
WEEE Nummer
DE90799723
Compare
Print view

Technical specifications

Description

Technical specifications

General

Packaged Quantity
1

Chassis

Built-in Devices
Status LCD, 2 x 2.5" SATA 6Gb/s drive bays

Processor

Type
Celeron
Installed Qty
1
Manufacturer
Intel
Clock Speed
1,8 GHz

RAM

Technology
DDR4 SDRAM
Form Factor
SO-DIMM 260-pin
Installed Size
4 GB
Max Supported Size
8 GB

Flash Memory

Installed Size
4 GB

Performance

Performance
Non-blocking bandwidth: 16 Gbps, Switching capacity: 32 Gbps

Ports

Qty
4
Type
10/100/1000 (PoE++)

Second Ports

Qty
10
Type
10/100/1000 (PoE+)

Third Ports

Qty
2
Type
Combo Gigabit SFP (PoE+)

Networking

Type
Switch
Ports Qty
16
MAC Address Table Size
8K entries
Power Over Ethernet (PoE)
PoE++
Jumbo Frame Support
9KB
PoE Budget
370 W
Smart
Yes

Expansion Slots

Expansion Slots
2 (total) / 2 (free) x PCI Express 2.0

Software

Type
QTS 4.4.1

Power Device

Power Consumption Operational
418 Watt
Frequency Required
50/60
Nominal Voltage
AC 120/230 V
Type
Internal power supply

System Requirements

OS Required
UNIX, Linux, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016, Microsoft Windows Server 2003

Dimensions & Weight

Weight
4,41 kg

Dimensions & Weight (Shipping)

Shipping Width
52,8 cm
Shipping Depth
40,3 cm
Shipping Height
16 cm
Shipping Weight
5,56 kg

Service & Support

Type
2-year warranty

Miscellaneous

Color Category
Black
Description
The QGD-1600P features SDN, enabling it to function as a NAS, NVR, router, firewall and AP controller for IP surveillance, network security, storage expansion, and wireless LAN management applications. Therefore, the Guardian series offers SMBs a cost-optimized and centrally managed LAN deployment solution.
  • Comprehensive layer 2 management features
    The QGD-1600P provides comprehensive Layer 2 management features such as VLAN, LACP, and LLDP for you to efficiently control the network through IP grouping and bandwidth management.
  • Dual-system of switch & NAS, enabling optimum performance
    The QGD-1600P features dual-system design, multi-port capability and expandable architecture, enabling optimum transmission and flexibility to fulfill business needs in performance and application diversification.
  • One-stop IP surveillance system
    The QGD-1600P works seamlessly with your surveillance software service, to help build a cost-effective one-stop IP surveillance system. By integrating PoE, NVR, and NAS storage functions, the QGD-1600P significantly simplifies the surveillance network infrastructure while satisfying the requirements for surveillance deployment, central management, video recording and computing.
