Please login to see the price and order.
Article-No.:
190546
Manufacturer-No.:
TS-873AEU-4G
EAN/GTIN:
4711103081075
WEEE Nummer
DE90799723
Suitable products
/asset/a/3/f/6/a3f640eb786210917d4cfd0fd8940c28ae8832b1_26d3aa03_051c_45ec_96ac_1855af750986.jpg "QNAP QM2-2P2G2T - storage controller - M.2 NVMe Card / PCIe 3.0 (NVMe) - PCIe 3.0 x4, 2.5 Gigabit Ethernet")
/asset/f/7/f/0/f7f0c2fd0359ba0fb6039e89bc84b3a19317cf7b_f2d4abb0_57de_4e30_9e55_6240086d0582.jpg "QNAP QM2-2P10G1TB - storage controller - PCIe 3.0 x4 (NVMe) - PCIe 3.0 x8")
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
Security DVR
IP Cameras Supported
8
Compression Format
MPEG-4, H.264
Chassis
Built-in Devices
LED panel
Processor
Type
Ryzen Embedded
Installed Qty
1
Max Supported Qty
1
Manufacturer
AMD
Clock Speed
2,2 GHz
Processor Number
V1500B
Number of Cores
Quad-Core
Max Turbo Speed
3,4 GHz
RAM
Technology
DDR4 SDRAM
Installed Size
4 GB
Max Supported Size
64 GB
Flash Memory
Installed Size
5 GB
Storage Controller
Interface Type
Serial ATA-600
Hard Drive
Type
HDD
Performance
Performance
Concurrent connections (CIFS): 2000 - (with maximum memory)
Networking
Network / Transport Protocol
PPTP, HTTP, HTTPs, IPv4, IPv6, L2TP, FTP, DHCP, SMB, DDNS, IPSec, iSCSI, NFS, SFTP
Network Services Compatibility
Network File System v3 (NFS v3), Network File System v4 (NFS v4), File Level Security (ACLs), DHCP, DDNS, Microsoft CIFS, FTP, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), SFTP
Host Connectivity (compact list)
2.5 Gigabit Ethernet
Expansion Bays
Expansion Bays
8 (total) / 8 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
Expansion Slots
2 (total) / 2 (free) x M.2 2280, 1 (total) / 1 (free) x PCI Express 3.0 x8, 2 (total) / 1 (free) x SO-DIMM 260-pin
OS Provided
Storage Operating System
QNAP QuTS hero h5.0.0 / QTS 5.0.0
Software
Type
McAfee AntiVirus
Power Device
Power Consumption Operational
70 Watt
Voltage Required
AC 100-240
Frequency Required
50/60
Power Provided
250 Watt
Installed Qty
1
Max Supported Qty
1
Nominal Voltage
AC 120/230 V
Type
Internal power supply
System Requirements
OS Required
SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11, Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Microsoft Windows Server 2016, Apple MacOS X 10.10 or later, CentOS 7.0, Microsoft Windows Server 2019
Dimensions & Weight
Width
48,2 cm
Depth
29,74 cm
Height
8,9 cm
Weight
7,61 kg
Dimensions & Weight (Shipping)
Shipping Weight
10,2 kg
Service & Support
Type
3-year warranty
Miscellaneous
Features
Alarm buzzer, Array roaming, Built-in 3 cooling fans, Online RAID Level Migration (RLM), Hardware encryption, Scheduled power on/off, Wake on LAN, S.M.A.R.T. support, Reset button, Secure Erase, Dual boot
Height (Rack Units)
2
Color Category
Black
Security Slot Type
Kensington security slot
Description
With its powerful AMD Ryzen V1000 series V1500B Quad-core processor, the TS-873AU is capable of boosting virtual machine performance with up to 4 cores/8 threads at 2.2GHz. The TS-873AU includes two 2.5GbE ports and a PCIe Gen 3 slot, providing you with fast network connectivity and the ability to add extra functionality and additional application potential. Cutting-edge hardware integrated with comprehensive software solutions makes the TS-873AU the preeminent choice to tackle resource-demanding applications and tasks. The TS-873AU supports QTS and QuTS hero, allowing users to flexibly switch operating system based on their requirements.
- Robust security
Equipped with 256-bit AES encryption, AES-NI, and support for multiple encryption algorithms including FIPS 140-2, SSL, TLS 1.0 to 1.3, this NAS server ensures your data is protected with advanced security measures. - Versatile connectivity
Offers a range of interface options including 2.5 Gigabit Ethernet, USB 3.2 Gen 2 Type-A and Type-C, ensuring high-speed connections and compatibility with various devices and networks. - High performance
Powered by an AMD Ryzen Embedded V1500B quad-core processor and 4 GB DDR4 SDRAM, it delivers reliable and efficient performance for handling concurrent connections and intensive data tasks. - Flexible storage options
Supports up to 8 hot-swap 2.5" / 3.5" drives and includes expansion slots for M.2 2280 and PCI Express 3.0 x8, offering ample and versatile storage configurations for your needs. - Comprehensive network services
Features a wide array of network services including VPN support, FTP/SFTP server, web server, and compatibility with multiple network file systems, making it an ideal solution for complex networking environments.
