Fractal Design Meshify 2 - tower - extended ATX

Fractal Design Meshify 2 - tower - extended ATX_thumb_1
Fractal Design Meshify 2 - tower - extended ATX_thumb_2
Fractal Design Meshify 2 - tower - extended ATX_thumb_3
Fractal Design Meshify 2 - tower - extended ATX_thumb_4
Fractal Design Meshify 2 - tower - extended ATX_thumb_5
Fractal Design Meshify 2 - tower - extended ATX_thumb_6
Fractal Design Meshify 2 - tower - extended ATX_thumb_7
Fractal Design Meshify 2 - tower - extended ATX_thumb_8
Fractal Design Meshify 2 - tower - extended ATX_thumb_9
Fractal Design Meshify 2 - tower - extended ATX_thumb_10
Fractal Design Meshify 2 - tower - extended ATX_thumb_11
Fractal Design Meshify 2 - tower - extended ATX_thumb_12
Fractal Design Meshify 2 - tower - extended ATX_thumb_13
Fractal Design Meshify 2 - tower - extended ATX_thumb_14
Fractal Design Meshify 2 - tower - extended ATX_thumb_15
Fractal Design Meshify 2 - tower - extended ATX_1
Fractal Design Meshify 2 - tower - extended ATX_2
Fractal Design Meshify 2 - tower - extended ATX_3
Fractal Design Meshify 2 - tower - extended ATX_4
Fractal Design Meshify 2 - tower - extended ATX_5
Fractal Design Meshify 2 - tower - extended ATX_6
Fractal Design Meshify 2 - tower - extended ATX_7
Fractal Design Meshify 2 - tower - extended ATX_8
Fractal Design Meshify 2 - tower - extended ATX_9
Fractal Design Meshify 2 - tower - extended ATX_10
Fractal Design Meshify 2 - tower - extended ATX_11
Fractal Design Meshify 2 - tower - extended ATX_12
Fractal Design Meshify 2 - tower - extended ATX_13
Fractal Design Meshify 2 - tower - extended ATX_14
Fractal Design Meshify 2 - tower - extended ATX_15
Article-No.:
242618
Manufacturer-No.:
FD-C-MES2A-03
EAN/GTIN:
7340172702443
WEEE Nummer
DE46285170
Compare
Print view

Similar products

Technical specifications

Description

Technical specifications

General

Packaged Quantity
1

Chassis

Form Factor
Tower
Internal Bays Qty
8
Video Card Max Length
491 mm
CPU Cooler Max Height
185 mm
Power Supply Max Length
250 mm
Windowed Side Panel
Yes

Cooling System

Cooling System
Front: 140 mm fan x 2 / 3 x 120/140 mm fan or 280/360mm radiator supported, Rear: 140 mm fan x 1 / 1 x 120/140 mm fan or 120mm radiator supported, Top: 120/140 mm fan mount x 3 / 360/420mm radiator supported, Bottom: 120/140 mm fan mount x 2 / 240/280mm radiator supported

Mainboard

Form Factor
Extended ATX
Supported Motherboards
ATX, microATX, Mini-ITX, Extended ATX

Expansion Bays

Expansion Bays
2 (total) / 2 (free) x internal - 2.5", 6 (total) / 6 (free) x internal - 2.5" / 3.5" shared

Expansion Slots

Expansion Slots
9

Power Device

Type
No power supply

Dimensions & Weight

Width
24 cm
Depth
54,2 cm
Height
47,4 cm
Weight
10,5 kg

Dimensions & Weight (Shipping)

Shipping Width
32,4 cm
Shipping Depth
54,2 cm
Shipping Height
63,4 cm
Shipping Weight
13,2 kg

Service & Support

Type
2-year warranty

Miscellaneous

Product Material
Steel
Color
Black
Color Category
Black
Description
The new Meshify 2 is a classic evolved with focus on distinctive design, spacious interior and rugged good looks.
  • Detachable front filter
    New front nylon filter that can be removed for increased airflow. New front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts. Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans.
  • Superlative storage
    Convert to storage layout and install up to 11 HDDs alongside four dedicated SSDs mounts (6x SSD/HDD trays, 2x SSD brackets and 1x multibracket included). Transformable interior design utilizing a movable wall for enhancing custom builds. The included multibracket lets you convert any unused fan position to an HDD, SSD or pump mount. Tool-less, top-latching side panels allow quick access while preventing accidental drops.
  • Extremely flexible
    Fits your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout. Support for radiators up to 360 mm (front), 420 mm (top) and 280 mm (base). Easily holds large motherboards up to and including 285 mm E-ATX.
  • Open and interchangeable
    Remove the entire top to build and route with zero hindrance.
  • Type-C interface
    USB 3.1 Gen 2 Type-C front I/O offers fast-charging and speeds up to 10 Gbps.
  • Nexus+ 2 fan hub
    Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans.
  • Versatile multibracket
    Versatile multibracket that converts any unused fan position to an HDD, SSD or pump mount.
  • Cable management
    Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board.
