Dell OptiPlex 7020 Plus - Small - Intel Core i7-14700

Article-No.:
239699
Manufacturer-No.:
40XJC
EAN/GTIN:
5397184852446

Suitable products

Similar products

Technical specifications

General

Packaged Quantity
1

System

Type
Personal computer
Platform Technology
Intel vPro Enterprise
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip

Chassis

Form Factor
Small form factor

Processor

Type
Core i7
Installed Qty
1
Max Supported Qty
1
Manufacturer
Intel
Clock Speed
2,1 GHz
Processor Main Features
28 Threads
Processor Number
I7-14700
Number of Cores
20-core
Max Turbo Speed
5,4 GHz

Mainboard

Chipset Type
Intel Q670

RAM

Technology
DDR5 SDRAM
Form Factor
DIMM 288-pin
Configuration Features
2 x 8 GB
Empty Slots
2
Slots Qty
4
Installed Size
16 GB
Max Supported Size
128 GB

Hard Drive

Installed Qty
1
Capacity
512 GB
Hard Drive Features
NVM Express (NVMe), Class 35
Type
SSD
Interface Class
PCI Express
SSD Form Factor
M.2 2230

Second Hard Drive

Type
None

Third Hard Drive

Type
None

Fourth Hard Drive

Type
None

Optical Storage

Drive Type
No optical drive

Second Optical Storage

Type
None
Drive Type
No optical drive

Blank Disk

Type
None

Display

Type
None.

Video Output

Graphics Processor
Intel UHD Graphics 770
Video Interfaces
HDMI, DisplayPort

Video Memory

Memory Allocation Technology
Shared video memory (UMA)

Audio Output

Compliant Standards
High Definition Audio

Printer

Type
None

Input Device

Type
Mouse (on selected markets only), Keyboard (on selected markets only)

Keyboard

Connectivity
Wireless
Keyboard Name
Dell KM5221W Pro Wireless Keyboard and Mouse Combo

Mouse

Connectivity
Wireless

Networking

Interface (Bus) Type
M.2 2230
Ethernet Controller(s)
Intel I219-LM
Wireless Protocol
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth
Wireless LAN Supported

Expansion Bays

Bays
Internal 3.5", 1 (total) / 1 (free) x external 5.25" Slim Line

Expansion Slots

Slots
1 (total) / 1 (free) x PCIe 3.0 x4 - half-height, 1 (total) / 1 (free) x PCIe 4.0 x16 - half-height, 1 (total) / 0 (free) x M.2 Card - 2230 (for WLAN), 1 M.2 Card - 2280 (for SSD), 2 M.2 Card - 2230 (for SSD)

OS Provided

Type
Windows 11 Pro
Language
Dutch / English / French / German / Italian
Family
Windows 11
Edition
Windows 11 Pro

Software

Type
Intel Connectivity Performance Suite, Dell Additional Softwares, No Microsoft Office License Included - 30 day Trial Offer Only, Intel Rapid Storage Technology

Power Device

Type
Power supply
Voltage Required
AC 90-264
Frequency Required
50/60
Power Provided
260 Watt
80 PLUS Certification
80 PLUS Bronze

Dimensions & Weight

Width
9,26 cm
Depth
29,28 cm
Height
29 cm
Weight
4,28 kg

Service & Support

Bundled Services
3 Years Basic Onsite Service after Remote Diagnosis with Hardware-Only Support

Miscellaneous

Color
Black
Color Category
Black
Theft/Intrusion Protection
Lockable cable covers, Security lock slot (cable lock sold separately), Padlock loop, Chassis intrusion switch
Security Slot Type
Kensington security slot
Description
The Dell OptiPlex 7020 Plus stands out as a high-performance personal computer designed to meet the demands of modern workplaces. At its core, a 20-core Intel Core i7 processor, coupled with DDR5 SDRAM, ensures seamless multitasking and efficient operation across various applications. Security is prioritized with a TPM 2.0 chip and physical anti-theft features, safeguarding sensitive information effectively.
Storage solutions are advanced, with an NVMe SSD providing quick data access and minimal load times, enhancing productivity. The inclusion of a wireless keyboard and mouse combo, along with Intel UHD Graphics 770, supports a clean, versatile workspace setup. Environmental considerations are also at the forefront, with ENERGY STAR certification and EPEAT compliance, making the Dell OptiPlex 7020 Plus an ideal choice for eco-conscious businesses looking to minimize their ecological impact while maximizing performance.
  • Efficient performance
    Equipped with a 20-core Intel Core i7-14700 processor and DDR5 SDRAM, the Dell OptiPlex 7020 Plus delivers robust performance and efficient multitasking capabilities. Its advanced architecture ensures smooth operation, even under heavy workloads.
  • Secure and reliable
    Featuring a Trusted Platform Module (TPM 2.0) security chip and various theft/intrusion protections, this desktop offers enhanced security measures to protect sensitive data and prevent unauthorized access.
  • High-speed storage
    With an NVMe SSD in the M.2 2230 form factor, the Dell OptiPlex 7020 Plus offers rapid data access and boot times, significantly improving overall system responsiveness.
  • Wireless convenience
    The inclusion of a wireless Dell KM5221W Pro Wireless Keyboard and Mouse Combo, along with wireless connectivity options, provides a clutter-free workspace and the flexibility to work from anywhere.
  • Eco-friendly design
    ENERGY STAR certification and EPEAT compliance signify the Dell OptiPlex 7020 Plus's commitment to environmental sustainability, reducing its carbon footprint while maintaining high performance.
