Product content
Product content
- Brother TD-4420TN
- USB cable
- Power adapter
/asset/d/3/d/8/d3d8b54f7f84b9ef31ab33a6957f8d8b24bf681d_f69d9139_b384_403b_b8e9_5d1f9678d8d3.jpg)
/asset/9/b/c/c/9bcc36742169eab130139dc149b89e3bcb803383_dc8895c5_ad64_4bde_ae40_8c5e28714fa4.jpg)
/asset/a/d/a/4/ada4e7e51775d9d6b69b52cbcebaf3a81956347c_3196c4ef_d83f_4e82_a4e9_e9ce6e515bfc.jpg)
/asset/f/0/e/3/f0e38b417e611a2ef1d25233de130f81a3e742bb_1d0a94ab_4bd6_4569_989b_41c8d69b46ac.jpg)
/asset/1/7/f/1/17f1edfedd6a21e7ad48d5ffe94ac963f259ca5d_4586615b_4070_4783_855e_c94d626c7a5c.jpg)
/asset/5/2/a/c/52acf1e9869aec0d940c867e5b77cc99d7b77620_f8007090_3e17_4f36_a0ef_05d4341ddaf0.jpg)
/asset/d/3/d/8/d3d8b54f7f84b9ef31ab33a6957f8d8b24bf681d_f69d9139_b384_403b_b8e9_5d1f9678d8d3.jpg)
/asset/9/b/c/c/9bcc36742169eab130139dc149b89e3bcb803383_dc8895c5_ad64_4bde_ae40_8c5e28714fa4.jpg)
/asset/a/d/a/4/ada4e7e51775d9d6b69b52cbcebaf3a81956347c_3196c4ef_d83f_4e82_a4e9_e9ce6e515bfc.jpg)
/asset/f/0/e/3/f0e38b417e611a2ef1d25233de130f81a3e742bb_1d0a94ab_4bd6_4569_989b_41c8d69b46ac.jpg)
/asset/1/7/f/1/17f1edfedd6a21e7ad48d5ffe94ac963f259ca5d_4586615b_4070_4783_855e_c94d626c7a5c.jpg)
/asset/5/2/a/c/52acf1e9869aec0d940c867e5b77cc99d7b77620_f8007090_3e17_4f36_a0ef_05d4341ddaf0.jpg)
Please login to see the price and order.
Article-No.:
131440
Manufacturer-No.:
TD4420TNZ1
EAN/GTIN:
4977766798556
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
Multifunctional Device
Type
Printer
Printing Output Type
Monochrome
Printing Technology
Direct thermal / thermal transfer
Functions
Printer
RAM
Installed Size
64 MB
Flash Memory
Installed Size
128 MB
Printer
Type
Label printer
Media Sizes
Roll (4 cm), Roll (11 cm)
Media Type
Continuous labels, Die cut labels, Fanfold paper
Connectivity Technology
Wired
Max Resolution B/W
203 dpi
Roll Maximum Outer Diameter
127 mm
Roll Core Diameter
25.4 mm, 38 mm
Features
Gap sensor, Transmissive media sensor, Label detection sensor
Media Thickness Range
0.06 mm - 0.19 mm
Max Printing Speed B/W
152,4 mm/sec
Max Printing Width
108 mm
Max Printing Length
25400 mm
Scanner
Type
None
Networking
Type
Print server
Security Protocols & Features
ARP, MAC address filtering
Software
Type
Drivers & Utilities
Power Device
Type
Power adapter
Form Factor
External
Frequency Required
50/60
Nominal Voltage
AC 120/230 V
System Requirements
OS Required
Linux, Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Windows 8, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Windows 8.1, Windows 10, Microsoft Windows Server 2016
Connectivity
Interface
USB host, RS232C, USB 2.0, LAN
Dimensions & Weight
Width
28 cm
Depth
20,4 cm
Height
17,75 cm
Weight
2,5 kg
Service & Support
Type
2-year warranty
Miscellaneous
Color Category
Black
Description
The Brother TD-4420TN label printer is engineered to meet the demands of high-volume printing environments. Featuring direct thermal and thermal transfer technology, it delivers monochrome printing output with a maximum resolution of 203 DPI. This model supports an extensive range of barcode formats, making it an ideal choice for retail, warehousing, and logistics applications.
With its robust connectivity options including LAN, RS232C, USB 2.0, and USB host, the TD-4420TN can easily integrate into various IT infrastructures. The printer's security protocols, such as ARP and MAC address filtering, ensure secure data communications. Additionally, its ability to handle different media types and sizes, combined with a fast print speed of up to 152 mm/s, enhances operational efficiency. Whether printing labels, tags, or receipts, the Brother TD-4420TN is designed to deliver reliability and performance.
With its robust connectivity options including LAN, RS232C, USB 2.0, and USB host, the TD-4420TN can easily integrate into various IT infrastructures. The printer's security protocols, such as ARP and MAC address filtering, ensure secure data communications. Additionally, its ability to handle different media types and sizes, combined with a fast print speed of up to 152 mm/s, enhances operational efficiency. Whether printing labels, tags, or receipts, the Brother TD-4420TN is designed to deliver reliability and performance.
- Versatile connectivity
With interfaces for LAN, RS232C, USB 2.0, and USB host, the Brother TD-4420TN offers flexible connectivity options to seamlessly integrate into existing systems. - Comprehensive barcode support
This label printer is capable of printing a wide range of barcodes including Aztec code, QR code, and UPC, making it suitable for various industry applications. - High-quality printing
Achieve crisp, clear printing with a maximum resolution of 203 DPI, perfect for producing readable labels, tags, and receipts. - Efficient media handling
Supports a variety of media types such as continuous labels, die cut labels, and fanfold paper, accommodating diverse printing needs. - Robust security features
Equipped with ARP and MAC address filtering, the Brother TD-4420TN ensures secure data transmission, safeguarding sensitive information.
