ATEN CS1922M - KVM / audio / USB switch - 2 ports

Article-No.:
205460
Manufacturer-No.:
CS1922M
EAN/GTIN:
4719264645822
WEEE Nummer
DE20263233
Technical specifications

General

Packaged Quantity
1

Chassis

Built-in Devices
USB 3.1 hub

Ports

Qty
2
Type
KVM / audio / USB

Networking

Type
KVM / audio / USB switch
Ports Qty
2

KVM

KVM V-Sync Rate At Max Resolution
60 Hz
KVM Max Supported Video Resolution
4096 x 2160
KVM Local Users Qty
1 local user
Keyboard / Mouse Interface
USB

Power Device

Power Consumption Operational
3,44 Watt

Dimensions & Weight

Width
21 cm
Depth
8,8 cm
Height
5,55 cm
Weight
730 g

Miscellaneous

Color Category
Black
Description
Incorporating the latest Multi-Stream Transport (MST) technology, the CS1922M 2-Port USB 3.0 4K DisplayPort MST KVMP Switch is the world's first DisplayPort KVM switch with a built-in MST hub. The CS1922M enables users to adopt two console displays from a single DisplayPort 1.2 video source, providing an extended desktop mode and splitter mode at resolutions up to 4K for multitasking across two displays while reducing bulky cable connections.
To meet the ever-increasing demand for high-speed peripheral data transmissions, the CS1922M integrates a USB 3.1 Gen 1 hub to deliver unprecedented data transfer rates up to 5 Gbps - allowing you to maximize multitasking operations.
The unique independent switching feature allows the KVM switch's focus to be on one computer while its USB peripheral focus is on another computer. This eliminates the need to purchase a separate USB hub or stand-alone peripheral sharer - such as a print server or splitter. Additionally, the switch allows you to share the audio from each of the connected computers and even allows HD audio transmitted through a DisplayPort source.
With a rich feature set, the CS1922M is designed to exceed the requirements such as excellent video quality and ultra-fast data transmission speed for gaming, graphic design, animation, and video-editing applications.
