Please login to see the price and order.
Article-No.:
270061
Manufacturer-No.:
90AR00M2-M00090
EAN/GTIN:
4711387781142
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
System
Type
PC barebone
Chassis
Form Factor
Ultra small form factor
Processor
Type
N-series
Installed Qty
1
Max Supported Qty
1
Manufacturer
Intel
Processor Number
N355
Number of Cores
8-core
Max Turbo Speed
3,9 GHz
RAM
Technology
DDR5 SDRAM
Form Factor
SO-DIMM 262-pin
Empty Slots
1
Slots Qty
1
Installed Size
0 GB
Max Supported Size
16 GB
Storage Controller
Interface Type
Serial ATA-600
Hard Drive
Type
No HDD
Second Hard Drive
Type
None
Third Hard Drive
Type
None
Fourth Hard Drive
Type
None
Optical Storage
Drive Type
No optical drive
Second Optical Storage
Type
None
Drive Type
No optical drive
Blank Disk
Type
None
Display
Type
None.
Video Output
Graphics Processor
Intel UHD Graphics
Video Interfaces
HDMI, DisplayPort
Audio Input
Type
None
Printer
Type
None
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 2.5 Gigabit Ethernet
Wireless NIC
Intel Wi-Fi 6E AX 211
Ethernet Controller(s)
Realtek RTL8125BG-CG
Wireless Protocol
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3
Wireless LAN Supported
Bluetooth
Expansion Slots
Slots
1 (total) / 1 (free) x M.2 Card - 2242/2280
OS Provided
Type
No operating system
Power Device
Type
Power adapter
Power Provided
65 Watt
Dimensions & Weight
Width
13,5 cm
Depth
11,5 cm
Height
3,6 cm
Weight
470 g
Miscellaneous
Color
Black
Color Category
Black
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Description
The ASUS NUC 14 Essential Kit is designed for those who need an ultra-compact PC without compromising performance. This mini PC features an Intel N-series processor with 8 cores, reaching speeds of up to 3.9 GHz, ensuring smooth multitasking and efficient processing. With support for DDR5 SDRAM, it allows for faster data transfer and improved system responsiveness. The integrated Intel UHD Graphics provides excellent video output support, including HDMI and DisplayPort, making it suitable for various applications. Connectivity options are abundant with multiple ports, including USB 3.2 Gen 2, USB-C, HDMI, DisplayPort, and 2.5 Gigabit Ethernet, ensuring enhanced data transfer and peripheral connectivity. The device is Wi-Fi 6E and Bluetooth 5.3 ready, providing a stable and fast wireless connection. The ultra-small form factor allows for easy placement in any workspace, making it an ideal choice for those needing versatility and compact design without sacrificing essential features.
- Efficient processing capabilities
Powered by an Intel N-series processor with 8 cores, the system can handle multiple tasks simultaneously with a maximum turbo speed of 3.9 GHz. - Robust connectivity options
Equipped with various ports including HDMI, USB 3.2 Gen 2, USB-C, and DisplayPort, users can easily connect multiple devices and peripherals. - High-speed wireless networking
Supports Wi-Fi 6E and Bluetooth 5.3, providing fast and reliable wireless connections for enhanced productivity and convenient features. - Space-saving design
The ultra-small form factor allows for easy placement in tight spaces, making it a perfect solution for home or office setups. - Integrated graphics support
Features Intel UHD Graphics that deliver smooth video performance, suitable for media playback and basic graphic tasks.
