Please login to see the price and order.
Article-No.:
256635
Manufacturer-No.:
90-MXBPL0-A0UAYZ
EAN/GTIN:
4710483949661
WEEE Nummer
DE46285170
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
Processor
Installed Qty
0
Max Supported Qty
1
Mainboard
Form Factor
Extended ATX
Chipset Type
Intel Z890
Supported RAM Technology
DDR5 SDRAM
Supported RAM Integrity Check
Non-ECC
Supported RAM Speed
5800 MHz (O.C.), 4800 MHz, 6800 MHz (O.C.), 4400 MHz, 5600 MHz, 9600 MHz (O.C.)
Processor Socket
LGA1851 Socket
Power Connectors
24-pin main power connector, 2 x 8-pin ATX12V connectors
Supported RAM (Registered or Buffered)
Unbuffered
RAM Slots
4 DIMM slots
Interfaces
Internal Interfaces
1 x USB-C 3.2 Gen 2x2 - header, 4 x USB 2.0 - header, 4 x USB 3.2 Gen 1 - header, 1 x SPI - header
RAM
Features
Intel Extreme Memory Profiles (XMP) 3.0, AMD EXPO technology, Dual channel memory architecture
Max Supported Size
256 GB
Video Output
Type
Graphics adapter (CPU required)
Audio Output
Type
Sound card
Compliant Standards
High Definition Audio
Audio Codec
Realtek ALC4082
Audio
High Definition Audio (8-channel)
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7), IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 2.5 Gigabit Ethernet
Network Controller
Marvell AQC113CS
Network
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4
Bluetooth
Expansion Slots
Expansion Slots
1 x CPU, 1 x PCIe 4.0 x4, 1 x M.2 socket (2242/2260/2280 M.2 Key M slot), 2 x PCIe 5.0 x16 (x8 mode), 1 x M.2 socket (Key E, for wireless module), 5 x M.2 socket (2280 M.2 Key M slot), 4 x DIMM 288-pin
Interfaces
Storage Interfaces
SATA-600 -connectors: 1 x Hyper M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 5.0 -connectors: 2 x Blazing M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 4.0 -connectors: 3 x Hyper M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
Storage
Serial ATA-600 (RAID), M.2 socket
USB / FireWire
USB4, USB-C 3.2 Gen2, USB-C 3.2 Gen 1
Storage Ports
4 x SATA-600 (RAID), 4 x Hyper M.2, 2 x Blazing M.2
USB / FireWire Ports Configuration (Active)
2 x USB4 + 4 x USB-C 3.2 Gen 2 + 4 x USB-C 3.2 Gen 1
USB / FireWire Ports Configuration (Headers)
2 x USB-C 3.2 Gen 2x2 + 4 x USB 3.2 Gen 1 + 4 x USB 2.0
Dimensions & Weight
Width
30,5 cm
Depth
27,4 cm
Description
The ASRock Z890 TAICHI AQUA motherboard is a robust platform designed for high-performance computing. Featuring support for Intel Core Ultra processors and advanced RAM specifications, this motherboard is engineered to meet the demands of power users and gamers alike. With support for DDR5 SDRAM and RAM speeds of up to 9600 MHz, it ensures rapid data processing and multitasking capabilities. The motherboard offers extensive connectivity options and expansion capabilities, including five expansion slots and multiple USB and storage interfaces that allow for a highly customizable PC build.
Additional features include Nahimic Audio Enhancer for immersive sound quality and ASRock's comprehensive BIOS suite, providing user-friendly settings tailored for both newcomers and seasoned builders. The inclusion of high-speed networking options - including 2.5 Gigabit Ethernet and Wi-Fi 7 compatibility - makes it a suitable choice for today's demanding online environments. With its unique aesthetic and powerful performance specs, the ASRock Z890 TAICHI AQUA is ideal for those who seek both functionality and style in their gaming or workstation setup.
Additional features include Nahimic Audio Enhancer for immersive sound quality and ASRock's comprehensive BIOS suite, providing user-friendly settings tailored for both newcomers and seasoned builders. The inclusion of high-speed networking options - including 2.5 Gigabit Ethernet and Wi-Fi 7 compatibility - makes it a suitable choice for today's demanding online environments. With its unique aesthetic and powerful performance specs, the ASRock Z890 TAICHI AQUA is ideal for those who seek both functionality and style in their gaming or workstation setup.
- Robust audio capabilities
Equipped with Realtek ALC4082 audio codec and high definition audio output for an immersive 8-channel sound experience - Extensive expansion options
Features 5 expansion slots including PCIe 4.0 and PCIe 5.0 support for enhanced performance and flexibility - Advanced networking support
Offers 2.5 Gigabit Ethernet and support for Wi-Fi 7 and Bluetooth 5.4 ensuring high-speed connectivity - User-friendly bios interface
Built with AMI UEFI BIOS featuring ASRock Instant Flash and customizable settings for optimum performance - Efficient power design
Incorporates a 28+1+2+1+1 Phase Power Design and VRM heatsink for stable and reliable performance
