ARCTIC P12 PWM PST A-RGB 0dB - case fan

ARCTIC P12 PWM PST A-RGB 0dB - case fan_thumb_3

ARCTIC P12 PWM PST A-RGB 0dB - case fan_1

ARCTIC P12 PWM PST A-RGB 0dB - case fan_2

ARCTIC P12 PWM PST A-RGB 0dB - case fan_3

Article-No.:

188657

Manufacturer-No.:

ACFAN00254A

EAN/GTIN:

4895213703529

WEEE Nummer

DE61101640

Compare

Print view

Technical specifications

General

Product Type

Case fan

Packaged Quantity

Heatsink & Fan

Fan Diameter

120 mm

Fan Height

25 mm

Rotation Speed

0-2000 rpm

Air Flow

48.8 cfm

Power Connector

4-pin fan socket, 4-pin fan connector

Features

RGB Fusion 2.0, Digital addressable RGB LEDs, ASUS Aura Sync, MSI Mystic Light Sync, ASRock Polychrome RGB, PWM Sharing Technology (PST), Pulse-width modulation (PWM) support, RGB LED x12, Vibration dampeners

Fan Bearing

Fluid dynamic bearing

Air Pressure

1.85 mm

Noise Level

0.3 Sone

Cable Length

40 cm

Dimensions & Weight

Width

12 cm

Depth

12 cm

Height

2,5 cm

Weight

131 g

Dimensions & Weight (Shipping)

Shipping Width

3 cm

Shipping Depth

12,7 cm

Shipping Height

12,5 cm

Shipping Weight

159 g

Service & Support

Type

6-year warranty

Miscellaneous

Color

White

Color Category

White

RGB

Description

RGB for full-color control
The P12 PWM PST A-RGB 0dB has 12 digital A-RGB LEDs in the fan scar. These can be controlled independently of each other and are compatible with the common A-RGB standards of leading motherboard manufacturers. The fan can thus be fully illuminated directly via the A-RGB mainboard connector or via an external controller and synchronized with the illumination of other hardware.
Maximum smoothness and minimum vibration
The operating noise of the newly developed ARCTIC motor is barely perceptible even at the lowest speed. In addition, the P12 PWM PST A-RGB 0dB has rubberized contact surfaces and thus reduces audible vibrations to a minimum.
Optimized for high static pressure
The P12 PWM PST A-RGB 0dB operates with a focused airflow and a high static pressure. The fan thus guarantees extremely efficient cooling, even with increased air resistance, and is therefore suitable for use on heat sinks, radiators and filters.
High-quality bearing
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. In this way, less heat develops, less bearing noise is generated and the service life of the fan is extended.
