ASRock Z890 TAICHI LITE - Motherboard - ATX - LGA1851-Sockel - Z890

1

0

1

ATX

Intel Z890

DDR5 SDRAM

Non-ECC

5800 MHz (O.C.), 4800 MHz, 6800 MHz (O.C.), 4400 MHz, 5600 MHz, 9600 MHz (O.C.)

LGA1851-Sockel

Hauptstromanschluss, 24-polig, 2 8-polige ATX12V-Anschlüsse

Ungepuffert

4 DIMM-Steckplätze

1 x USB-C 3.2 Gen 2x2 - Stiftleiste, 1 x Audio - Stiftleiste, 4 x USB 2.0 - Stiftleiste, 4 x USB 3.2 Gen 1 - Stiftleiste, 1 x SPI - Stiftleiste

Intel Extreme Memory Profiles (XMP) 3.0, Zwei-Kanal-Speicherarchitektur

256 GB

Grafikadapter (CPU erforderlich)

Soundkarte

High-Definition-Audio

Realtek ALC4082

High Definition Audio (5.1-Channel)

Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7), IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 5 Gigabit Ethernet, 2.5 Gigabit Ethernet

Dragon RTL8125BG / Realtek RTL8126

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4, 5 Gigabit Ethernet

1 x CPU, 1 x M.2 socket (2230 M.2 Key E Steckplatz), 1 x M.2 socket (2280 M.2 Key M Steckplatz), 1 x PCIe 5.0 x16, 1 x M.2 socket (2230/2242/2260/2280 M.2 Slot mit Key M), 4 x M.2 socket (2260/2280 M.2 Key M Slot), 4 x DIMM 288-polig, 1 x PCIe 4.0 x16 (x4-Modus)

PCIe 4.0 -anschlussstellen: 4 x Hyper M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 / PCIe 4.0 -anschlussstellen: 1 x Hyper M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 5.0 -anschlussstellen: 1 x Blazing M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 -anschlussstellen: 4 x 7-Pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5

Hyper M.2 socket, Blazing M.2 socket, Serial ATA-600 (RAID)

USB 3.2 Gen 1, USB 3.2 Gen 2, USB4, USB-C 3.2 Gen 2x2

4 x SATA-600 (RAID), 5 x Hyper M.2, 1 x Blazing M.2

2 x USB4 + 4 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + 2 x USB 2.0

1 x USB-C 3.2 Gen 2x2 + 4 x USB 3.2 Gen 1 + 4 x USB 2.0

ASRock Dragon 2.5G LAN Software, ASRock A-Tuning

30,5 cm

24,4 cm
